Custom Poly Bubble Honeycomb Kraft Paper Mailer Padded Envelopes Making machine

The honeycomb mailer can instead the current bubble film mailer for economic and environmental protection. Under the background of
plastic ban, it has very huge market. It can be widely used as outer package for mailing clothes, small accessory, food and file etc.
Mechanical speed:
One line:
Double line:
Maximum length of bag (width of bag):
Maximum width of unwinding:
Maximum diameter of unwinding:
Machine weight:
Availability:
Quantity:
  • KXT-FW800

  • KOXTE

  • 8449009000

The honeycomb mailer can instead the current bubble film mailer for economic and environmental protection. Under the background of plastic ban, it has very huge market. It can be widely used as outer package for mailing clothes, small accessory, food and file etc.

It can protect the products in environmental friendly way. And it will be a very good product which can instead the plastic bubble film in the future.

Sample:

23416-942

1. The surface paper (Outside Kraft paper) and the inner side paper must be 110g/m² Kraft paper.

2. Because of the original honeycomb paper width is under 500mm, when making different size of bags, have to lap joint the redundant paper in the middle.

3. The glue for heat seal after folding can be provided by our company.

Brief Introduction:

1. This machine is special designed for making bags which laminate the Kraft paper and Honeycomb paper by glue.

2. Bag making method: Fixed the Kraft paper and honeycomb paper (by stretching) into two layers of Kraft paper by fixed point glue spraying method, and then by, second gluing, folding and cutting into a environmentally cushion bag which used in express industry.

3. This machine uses multi point advanced motion controller technology. It is controlled by computer program from film unwinding to cutting. This machine is a high-quality, easy-operational and professional one to make good-looking a, durable and environment-friendly bags.


professionoal designed for honeycomb cushion bags


Suitable bags
professionoal designed for honeycomb cushion bags.
Mechanical speed
1000-1500pcs/hour
Max width of bag (Height of bag)
One line: 550mm
Double line: 300mm
Maximum length of bag (width of bag)
500mm
Maximum width of unwinding
Kraft paper: 1200mmX2
honeycomb paper 500mmx4
Maximum diameter of unwinding
Kraft paper 1000mm
honeycomb paper 500mm
Kraft paper 1000mm, honeycomb paper 500mm
17000KGS
Overall Dimension
30000*2300*2400mm
Power required
60KW
Voltage
380V 50Hz Three Phase Five wire
