Bag making speed: | |
---|---|
Mechanical speed: | |
Bag making width : | |
bag making length: | |
Discharge gas expansion shaft: | |
Power supply voltage: | |
Total power: | |
Availability: | |
Quantity: | |
KXT-AP800/1200
KOXTE
Automatic air cushion film making machine also called Automatic air cushion film rolls making machine is sealing air way, seal film side and cross-cut in one line, suitable for PE co-extruded packaging film. The products are widely used in packaging electronic products, shredded products, bags and other items filled in the center to get the more refined and beautiful packaging products. automatic air pillow bag making machine is power saving, high efficiency and simple operation, mechatronics equipment.
Our Automatic Plastic Air Bubble Film Bag Making Machine are perfect for companies that need to produce bubble wrap quickly and efficiently. These machines produce high-quality bubble wrap at a speed that is ideal for large-scale production environment.
1, Widely frequency range of inverters are controlling the whole production line, stepless speed changing, individual release and pick up motors make production more productive.
2, Automatic air cushioning film production line is easy to load and unload products with air shafts in the rewinding and unwinding parts
3, The machines have functions like auto homing, auto alarming and auto stop etc.
4, Automated air pillow packaging making machine.is equipped with fully automatic EPC device on unwinding part to make film even.
5, Rewinding &unwinding parts are with high function potential sensor to ensure continuous film delivery and stable unwinding.
6, Air Bubble Film Bag Making Machine adopts inter-grating device of motor reducer brake all-in-one, without belt chains or noise. Its stability &precision are much higher.
7, machine’s unwinding is with photo-eye EPC to make film more flat and tighter.
8. Not the longest history machine but the most upgraded model in China. More and more famous packaging companies upgrade air column cushion bag production line with our machines.
Technical Parameters
Machine Model | KXT-AP1200 |
Color | Green(According to your requirement) |
Max. Film Roll Width | 1200mm |
Max. Film Roll Diameter | 650mm |
Bag making speed | 150-170times/min |
Mould Dimension | 360*1200mm |
Air Supply | 0.6MPa |
Power Supply | 380V/50Hz, Three Phase Four Wires |
Heating Power | 14.2KW |
Total Power | 22.0KW |
Weight | 3200KGS |
Machine Dimension | 6660*2480*1650mm |
Automatic air cushion film making machine also called Automatic air cushion film rolls making machine is sealing air way, seal film side and cross-cut in one line, suitable for PE co-extruded packaging film. The products are widely used in packaging electronic products, shredded products, bags and other items filled in the center to get the more refined and beautiful packaging products. automatic air pillow bag making machine is power saving, high efficiency and simple operation, mechatronics equipment.
Our Automatic Plastic Air Bubble Film Bag Making Machine are perfect for companies that need to produce bubble wrap quickly and efficiently. These machines produce high-quality bubble wrap at a speed that is ideal for large-scale production environment.
1, Widely frequency range of inverters are controlling the whole production line, stepless speed changing, individual release and pick up motors make production more productive.
2, Automatic air cushioning film production line is easy to load and unload products with air shafts in the rewinding and unwinding parts
3, The machines have functions like auto homing, auto alarming and auto stop etc.
4, Automated air pillow packaging making machine.is equipped with fully automatic EPC device on unwinding part to make film even.
5, Rewinding &unwinding parts are with high function potential sensor to ensure continuous film delivery and stable unwinding.
6, Air Bubble Film Bag Making Machine adopts inter-grating device of motor reducer brake all-in-one, without belt chains or noise. Its stability &precision are much higher.
7, machine’s unwinding is with photo-eye EPC to make film more flat and tighter.
8. Not the longest history machine but the most upgraded model in China. More and more famous packaging companies upgrade air column cushion bag production line with our machines.
Technical Parameters
Machine Model | KXT-AP1200 |
Color | Green(According to your requirement) |
Max. Film Roll Width | 1200mm |
Max. Film Roll Diameter | 650mm |
Bag making speed | 150-170times/min |
Mould Dimension | 360*1200mm |
Air Supply | 0.6MPa |
Power Supply | 380V/50Hz, Three Phase Four Wires |
Heating Power | 14.2KW |
Total Power | 22.0KW |
Weight | 3200KGS |
Machine Dimension | 6660*2480*1650mm |
