Plastic Mylar Ziplock Stand Up Flat Bottom Pouch Powder Aluminum Foil Roll Film Food Valve Food Tea Coffee Bean Packaging Bag Making Machine

two-layer or multi-layer three-side sealing laminated film pouches and doy-pack making function which take BOPP, PET, CPP, PE, nylon, aluminum foil and paper as base material.

Width of unwind before fold:	850MM
Pouch-making Length:	50-2400mm
Pouch-making Width:	70-400mm
Capacity:	40-150pcs/min
Set film dragging speed:	35m/min
Availability:

Quantity:



Inquire Add to Basket

Model:
ZUD-400
Brand:
KXITE

Product Description

Function: Three-side sealing & Standing Bag & Secondary cutter
Main Electric Device: Three Servo Motor, Panasonic PLC, AC motor masterdrive, Panasonic frequency converter, Temperature control 24 Road, Tension control unwinding.
Base material: two-layer or multi-layer three-side sealing laminated film pouches and doy-pack making function which take BOPP, PET, CPP, PE, nylon, aluminum foil and paper as base material.

Brief Introduction:

Heavy duty laminated bag making machine, is used for producing various kinds of laminated soft package bag, also it can make center sealing bag, four side sealing bag and five side sealing bag.

Feature:

It is multi function machine,to make zipper stand up bags, 3 side sealing bag & center sealing bag
Large human-computer interface screen control, automatic design and PLC control.
Heavy-duty heat sealing structure,will get stronger sealing
It has EPC and double photocell tracking for unwinding
Unwinding with automatic tension control

option:
1.Double layer unwinder device
2.Punching device for handle.

Technical Parameter:

Type	ZUD-400	ZUD-500	ZUD-600
Width of unwind before fold	850mm	1050mm	1250mm
Pouch-making Length	50-2400mm	50-2400mm	50-2400mm
Pouch-making Width	70-400mm	70-500mm	70-600mm
Capacity	40-150pcs/min	40-150pcs/min	40-150pcs/min
Set film dragging speed	35m/min	35m/min	30m/min
Total Power	55kw	60kw	65kw
Weight of Machine	6500kg	7000kg	7500kg
Overall Dimension	1310018002000mm	1310020002000mm	1310022002000mm

Heavy Duty Three Side Seal Zipper Stand up Pouch Machine

ZUD-A 微信截图_20240622233857 81fe1a81-0758-4f4c-81cd-cf492a484a5c zuy

Coffee Packaging Bag Making Machine Bean Packaging Bag Making Machine Flat Bottom Packaging Bag Making Machine Stand Up Packaging Bag Making Machine Ziplock Packaging Bag Making Machine food Packaging Bag Making Machine Valve Packaging Bag Making Machine Tea Packaging Bag Making Machine Coffee Packaging Pouch Making Machine Stand up Pouch Making Machine
